⚙️ AppShell

A dependency-free application runtime and domain foundation for Rust.
App Engine (runtime infrastructure) + Domain Foundation (reusable domain models) — all in one coherent library.

Features · Quick Start · Architecture · Guides

What Is This?¶

AppShell is a two-layer library for building Rust applications:

App Engine — generic application runtime infrastructure (lifecycle, commands, tasks, scheduling, events, signals, history, resources, services, plugins, configuration) without knowing what your application does.
Domain Foundation — reusable, headless domain models (Canvas2D, Timeline, Layers, NodeGraph, Viewport3D, Table, TextEditor, Relations, Utilities) that sit between the App Engine and your application-specific Domain Engine.

flowchart TD
    subgraph AE["APP ENGINE"]
        EX["Execution<br/>Commands<br/>Tasks<br/>Scheduler<br/>Resources"]
        CM["Communication<br/>Events<br/>Signals<br/>History"]
        XT["Extension<br/>Plugins<br/>Services<br/>Permissions"]
        SP["Supporting<br/>Runtime + Lifecycle (+ cleanup)<br/>Context + State (thread-safe)<br/>Configuration + Preferences (+ persistence)<br/>Execution Control (cancel, deadline, stream)<br/>Concurrency (thread-safe, async, TaskPool)<br/>Serialization (Serializer, registry, IPC)<br/>Testing (mocks, TestEngine, assertions)<br/>Metadata (Version, PayloadSchema)"]
        RL["Reliability<br/>Panic isolation (catch_unwind)<br/>Event priority (High/Normal/Low)<br/>Retry policies (Fixed/Exponential)<br/>RAII resource handles (auto-release)"]
    end
    subgraph DF["DOMAIN FOUNDATION"]
        ENV["Environments<br/>Canvas2D, Timeline, Layers<br/>NodeGraph, Viewport3D, Table, TextEditor"]
        REL["Relations<br/>Priority-sorted evaluation<br/>Batch propagation<br/>Value source/sink traits"]
        UTIL["Utilities<br/>Filtering, Querying, Tagging<br/>Sorting, Grouping, Validation, Batch"]
    end
    AE -->|"contracts"| DF
    DF -->|"composes"| DE["DOMAIN ENGINE<br/>(app meaning)"]
    DE -->|"integration"| API["API / MCP / UI"]

Zero external dependencies by default. Optional tokio for async. Optional serde for serialization.

Comparison¶

Feature	App Engine	Domain Foundation	bevy_app	tokio	iced	tauri
Lifecycle	✅ 5-state	—	✅	❌	❌	❌
Commands	✅	—	❌	❌	❌	❌
Tasks	✅	—	❌	✅	❌	❌
Scheduler	✅	—	❌	✅ (async)	❌	❌
Events	✅ priority + isolation	—	❌	❌	❌	❌
Signals	✅ thread-safe	—	❌	❌	✅	❌
History	✅ undo/redo/replay	—	❌	❌	❌	❌
Resources	✅ RAII + deps	—	❌	❌	❌	❌
Services	✅ panic-isolated	—	✅	❌	❌	❌
Plugins	✅ permissions	—	✅	❌	❌	✅
Config	✅ persistent	—	❌	❌	❌	✅
Persistence	✅ file/memory	—	❌	❌	❌	❌
Serialization	✅ zero deps	✅ optional serde	❌	❌	❌	❌
Concurrency	✅ Send + Sync	✅ Send + Sync	✅	✅	❌	❌
Async	✅ optional tokio	—	❌	✅	❌	❌
Panic isolation	✅ all handlers	—	❌	❌	❌	❌
2D Canvas	—	✅ headless	❌	❌	❌	❌
Timeline	—	✅ headless	❌	❌	❌	❌
Layers	—	✅ hierarchy	❌	❌	❌	❌
NodeGraph	—	✅ + Canvas2D	❌	❌	❌	❌
Viewport3D	—	✅ headless	❌	❌	❌	❌
Table	—	✅ + merged cells	❌	❌	❌	❌
TextEditor	—	✅ Unicode	❌	❌	❌	❌
Relations	—	✅ priority + batch	❌	❌	❌	❌
Undoable ops	—	✅ all operations	❌	❌	❌	❌
Dependencies	zero by default	zero by default	many	tokio	many	many

Features¶

App Engine — Execution Systems¶

System	What It Does
Commands	Application intents — "do X." Registered, executed, panic-isolated.
Tasks	Managed work with lifecycle: `Pending → Running → Completed/Failed/Cancelled`. Cancellation, deadlines, progress streaming.
Scheduler	Decides when tasks run: immediate, delayed, interval, triggered. Priority queue. Retry policies with fixed/exponential backoff.
Resources	Load, cache, track, and release generic data. RAII handles auto-release on drop. Dependency tracking. Thread-safe.

App Engine — Communication Systems¶

System	What It Does
Events	"Something happened." One-to-many, priority-ordered, panic-isolated. Serialized payload support for IPC.
Signals	"Something changed." Lightweight, thread-safe. Progress streaming from task handlers.
History	Ordered operations with undo/redo/replay/transactions. Persistence-ready.

App Engine — Extension Systems¶

System	What It Does
Services	Long-lived capabilities that start/stop with the app. Panic-isolated lifecycle.
Plugins	Extension packages contributing commands, tasks, resources, services, handlers. Permission-controlled. Dynamic loader stub for `.so`/`.dll`.

App Engine — Foundation Systems¶

System	What It Does
Runtime + Lifecycle	Owns the application lifetime. Cancels tasks on stop. Unloads resources on dispose.
Context	Identity hierarchy: `Application → Session → Execution`.
State	Generic key-value state store with validated transitions. Thread-safe.
Configuration	Persistent settings. File/memory backends. Change notifications. Thread-safe.
Preferences	User-facing settings. Thread-safe.
EngineRef	Read-only bundle of subsystems passed to handlers. Handlers can publish events, load resources, write config, submit to scheduler.
Execution Control	`CancellationToken`, `Deadline`, `TaskOutputChannel`.
Persistence	`StorageBackend` trait with `FileStorageBackend` and `MemoryStorageBackend`.
Serialization	`Serializer` trait + `SerializationRegistry`. Serialized bytes on all payloads for IPC. Zero external deps.
Concurrency	All managers `Send + Sync`. `TaskPool`. Optional `AsyncRuntime` (tokio).
Panic Isolation	All handler calls wrapped in `catch_unwind`. Mutex not poisoned.
Testing	`MockCommandExecutor`, `MockEventBus`, `MockSignalBus`, `TestEngine`, assertion helpers.
Metadata	`Version`, `PayloadSchema` on all definitions.

Domain Foundation — Environments¶

Environment	What It Does
Canvas2D	Arbitrary 2D spatial organization with objects, transforms, z-ordering, spatial queries.
Timeline	Temporal organization with tracks, clips, keyframes, interpolation, overlap constraints.
Layers	Hierarchical organization with parent-child, visibility inheritance, reparenting.
NodeGraph	Graph connectivity with ports, edges, type matching, topological sort. Composes Canvas2D.
Viewport3D	3D spatial organization with Euler angles, parent-child transforms, spatial queries.
Table	Tabular data with rows, columns, cells, merged cells, ordering, swap operations.
TextEditor	Headless text editing with Unicode positions, ranges, search/replace, line/column.

Domain Foundation — Relations¶

Feature	What It Does
Definitions	Declarative relation metadata: endpoints, trigger, propagation mode, priority.
Evaluation	Apply developer-supplied effect closures when source properties change.
Propagation	Direct or cascading with cycle protection and max depth.
Batch	Accumulate multiple property changes and propagate together.
Value Source/Sink	Traits for bridging Domain Engine state to evaluation engine.

Domain Foundation — Utilities¶

Utility	What It Does
Filtering	Composable predicates (AND/OR/NOT) over any data type.
Querying	Named, reusable queries built on filtering.
Tagging	Tags and tag sets with deterministic iteration (BTreeSet).
Sorting	Criteria-based ordering, in-place or non-mutating.
Grouping	Group by key, with deterministic sorted output.
Validation	Rules, multi-rule validation, collect all failures.
Batch	Multi-object operations via trait or closure.

Quick Start¶

App Engine¶

use app_shell::app_engine::*;
use std::any::Any;

// --- Your command handler ---
struct GreetCommand;

impl CommandHandler for GreetCommand {
    fn execute(
        &self,
        input: &CommandInput,
        _: &CommandContext,
        engine: &EngineRef,
    ) -> Result<CommandResult, CommandError> {
        let name: &String = input.get::<String>()
            .ok_or_else(|| CommandError::InvalidArguments("expected name".to_string()))?;

        engine.event_bus.publish(
            &Event::new("greet.done").with_source("GreetCommand")
        );

        Ok(CommandResult::success_with(format!("Hello, {}!", name)))
    }
}

// --- Main ---
fn main() {
    let mut engine: AppEngine = Bootstrap::create().expect("bootstrap failed");

    engine.command_executor_mut().register(
        CommandDefinition::new("app.greet", "Greet", "Greet someone"),
        Box::new(GreetCommand),
    ).unwrap();

    engine.initialize().unwrap();
    engine.start().unwrap();

    let cmd = Command::new(
        "app.greet",
        CommandContext::new(ExecutionId::new()),
        CommandInput::new("World".to_string()),
    );
    let result = engine.execute_command(&cmd).unwrap();
    println!("{}", result.output::<String>().unwrap());

    engine.stop().unwrap();
    engine.dispose().unwrap();
}

Domain Foundation¶

use app_shell::domain_engine::DomainEngine;
use app_shell::domain_foundation::environments::canvas_2d::*;

let mut engine = DomainEngine::new();

// Create a canvas object
let id = engine.execute_canvas(CanvasOperation::Create {
    transform: Transform::from_translation(Vec2::new(100.0, 200.0)),
}).unwrap();

// Move it
engine.execute_canvas(CanvasOperation::Move {
    id,
    translation: Vec2::new(50.0, 50.0),
}).unwrap();

// Undo
engine.undo().unwrap();
assert_eq!(
    engine.canvas().get(id).unwrap().transform.translation,
    Vec2::new(100.0, 200.0),
);

// Transactions
engine.begin_transaction();
engine.execute_canvas(CanvasOperation::Create { transform: Transform::identity() }).unwrap();
engine.execute_canvas(CanvasOperation::Create { transform: Transform::identity() }).unwrap();
engine.commit_transaction();

// Undo both as one unit
engine.undo().unwrap();
assert_eq!(engine.canvas().len(), 0);

Architecture¶

flowchart TD
    R["Runtime"] --> C["Context"]
    R --> S["State"]
    R --> CF["Configuration"]
    S --> G1["Commands<br/>Tasks<br/>Scheduler<br/>Resources"]
    G1 --> G2["Events<br/>Signals<br/>History"]
    G2 --> G3["Services<br/>Plugins<br/>Preferences"]

Dependency Direction¶

Domain Engine  ──→  Domain Foundation  ──→  App Engine  ──→  (nothing)
App Engine     ✗→   Domain Foundation
Domain Engine  ✗→   App Engine (directly)
App Engine     ✗→   UI / API / MCP

Layered Architecture¶

flowchart TD
    A["External Layer (UI / API / MCP / CLI)"] -->|"commands"| B["Domain Engine (application meaning)"]
    B -->|"composes"| C["Domain Foundation (reusable domain models)"]
    C -->|"uses contracts"| D["App Engine (runtime infrastructure)"]

Each layer knows only the layer below it. The App Engine never imports domain types. The Domain Foundation never imports UI types.

Installation¶

Add to your Cargo.toml:

[dependencies]
app_shell = { path = "path/to/AppShell" }

# Optional: async runtime
app_shell = { path = "path/to/AppShell", features = ["async-runtime"] }

# Optional: serialization
app_shell = { path = "path/to/AppShell", features = ["serde"] }

Features¶

Feature	Description
`default`	Zero external dependencies. All systems included (sync only).
`async-runtime`	Adds `tokio` for async task execution via `AsyncTaskHandler`.
`serde`	Adds `serde` derives on all serializable Domain Foundation types.

Key Properties¶

Property	App Engine	Domain Foundation
Dependency-free	✅ Zero external crates by default	✅ Zero external crates by default
Thread-safe	✅ All managers are `Send + Sync`	✅ All environments are `Send + Sync`
Panic-isolated	✅ All handler calls wrapped in `catch_unwind`	—
RAII resources	✅ Handles auto-release on drop	—
Backward compatible	✅ Default permissions = `FULL_ACCESS`	—
Headless	✅ Runs without UI, API, or MCP	✅ No UI, rendering, or input
Serializable	✅ `Serializer` trait, zero deps	✅ Optional `serde` feature
Persistent	✅ `StorageBackend` trait, file + memory	—
Testable	✅ Mocks, `TestEngine`, assertion helpers	✅ 414 tests + proptest + benchmarks
Versioned	✅ `Version`, `PayloadSchema` on all definitions	—
Async-ready	✅ Optional `tokio` integration	—
Composable	—	✅ Environments compose concretely
Undoable operations	—	✅ Every operation carries undo data
Unicode-aware	—	✅ TextEditor uses Unicode scalar value positions
Priority-sorted relations	—	✅ Higher priority relations fire first
Cycle-safe	—	✅ Propagator + Layer/Viewport3D reject cycles

Subsystem Summary¶

flowchart TD
    subgraph APPSHELL["APPSHELL"]
        subgraph AE["APP ENGINE"]
            EX["Execution"]
            CO["Communication"]
            EN["Extension"]
            FO["Foundation"]
            RE["Reliability"]

            EX --> EX1["Commands (intent → execution, panic-isolated)"]
            EX --> EX2["Tasks (managed work, cancel, deadline, progress)"]
            EX --> EX3["Scheduler (when work runs, retry, triggers)"]
            EX --> EX4["Resources (load, cache, RAII handles, dependencies)"]

            CO --> CO1["Events (one-to-many, priority, panic-isolated)"]
            CO --> CO2["Signals (lightweight change notifications)"]
            CO --> CO3["History (undo/redo/replay/transactions)"]

            EN --> EN1["Services (long-lived, panic-isolated lifecycle)"]
            EN --> EN2["Plugins (extension packages, permission-controlled)"]

            FO --> FO1["Runtime + Lifecycle (+ cleanup on stop/dispose)"]
            FO --> FO2["Context (Application → Session → Execution)"]
            FO --> FO3["State (generic key-value, thread-safe)"]
            FO --> FO4["Configuration (persistent, thread-safe, change notifications)"]
            FO --> FO5["Preferences (user-facing, thread-safe)"]
            FO --> FO6["EngineRef (handler capabilities)"]
            FO --> FO7["Execution Control (cancel, deadline, stream)"]
            FO --> FO8["Persistence (StorageBackend trait)"]
            FO --> FO9["Serialization (Serializer trait, registry)"]
            FO --> FO10["Concurrency (TaskPool, AsyncRuntime)"]
            FO --> FO11["Testing (mocks, TestEngine)"]
            FO --> FO12["Metadata (Version, PayloadSchema)"]

            RE --> RE1["Panic Isolation (catch_unwind on all handlers)"]
            RE --> RE2["Event Priority (High/Normal/Low)"]
            RE --> RE3["Retry Policies (Fixed/Exponential)"]
            RE --> RE4["RAII Handles (auto-release on drop)"]
        end

        subgraph DF["DOMAIN FOUNDATION"]
            ENV["Environments"]
            REL["Relations"]
            UTI["Utilities"]

            ENV --> E1["Canvas2D (objects, transforms, z-order, spatial queries)"]
            ENV --> E2["Timeline (tracks, clips, keyframes, interpolation)"]
            ENV --> E3["Layers (hierarchy, visibility inheritance, reparenting)"]
            ENV --> E4["NodeGraph (ports, edges, type matching, topo sort)"]
            ENV --> E5["Viewport3D (3D transforms, parent-child, spatial queries)"]
            ENV --> E6["Table (rows, columns, cells, merged cells, ordering)"]
            ENV --> E7["TextEditor (Unicode positions, ranges, search/replace)"]

            REL --> R1["Definitions (endpoints, trigger, propagation, priority)"]
            REL --> R2["Evaluation (effect closures, mutable value store)"]
            REL --> R3["Propagation (Direct, Cascading, cycle protection)"]
            REL --> R4["Batch (accumulate, commit, rollback)"]
            REL --> R5["Value Source/Sink (bridge Domain Engine state)"]

            UTI --> U1["Filtering (AND/OR/NOT composable predicates)"]
            UTI --> U2["Querying (named, reusable queries)"]
            UTI --> U3["Tagging (BTreeSet, deterministic order)"]
            UTI --> U4["Sorting (criteria-based ordering)"]
            UTI --> U5["Grouping (group by key, sorted output)"]
            UTI --> U6["Validation (rules, multi-rule, collect failures)"]
            UTI --> U7["Batch (multi-object operations)"]
        end
    end

    AE -->|"contracts"| DF
    DF -->|"composes"| DE["DOMAIN ENGINE (app meaning)"]

When to Use¶

✅ Use AppShell when: - You need managed execution (commands, tasks, scheduling) - You need undo/redo with transactions - You need reusable domain models (2D canvas, timeline, layers, node graph, table, text editor) - You need property propagation between objects (relations) - You need plugin extensibility with permission control - You need decoupled communication (events/signals) - You need resource management with RAII handles - You need long-lived services with panic isolation - You need thread-safe managers (Send + Sync) - You need async execution (optional tokio) - You need serialization for IPC or persistence (zero deps or serde) - You want stable contracts between runtime, domain models, and domain logic

❌ Don't use AppShell if: - Your app is a simple script - You have no lifecycle/undo/extensibility/domain-model needs - You don't need domain/UI/API separation

License¶

Apache-2.0

Contributing¶

(Not Yet) ~~Pull requests welcome. See the architecture guide before contributing — clean boundaries are the core value proposition.~~

Guides¶

App Engine — Core Architecture¶

#	Guide	Topic
01	Overview	What App Engine is, what it provides, what it doesn't
02	Architecture	Layering, boundaries, subsystem ownership
03	Bootstrap & Lifecycle	Creating, running, shutting down
04	Context & State	Identity hierarchy, state management
05	Commands & Tasks	Intents, managed work, registration, execution
06	Scheduling & Communication	Scheduler, events, signals
07	History & Resources	Undo/redo, RAII handles, dependencies
08	Services & Plugins	Long-lived capabilities, extensions, permissions
09	Domain Engine Integration	How to build your domain layer
10	Application Integration	UI, API, MCP, CLI, headless

App Engine — Advanced Features¶

#	Guide	Topic
11	Handler Capabilities	EngineRef, what handlers can access
12	Execution Control	Cancellation, deadlines, progress streaming
13	Persistence & Serialization	Storage backends, Serializer trait, IPC
14	Concurrency & Async	Thread safety, TaskPool, AsyncRuntime
15	Communication & Reliability	Priority, panic isolation, retry
16	Testing & Metadata	Mocks, TestEngine, Version, PayloadSchema
17	Plugin Security	Permissions, PermissionCheckedEngineRef

App Engine — Reference¶

#	Guide	Topic
18	Public API Reference	Complete type/trait listing
19	Error Reference	All error types and variants
20	Quick Start	5-minute getting started

Domain Foundation — Overview¶

#	Guide	Topic
01	Overview	What Domain Foundation is, what it provides, what it doesn't
02	Architecture	Layering, composition rules, dependency direction
03	Environments	All 7 environments at a glance

Domain Foundation — Environments¶

#	Guide	Topic
04	Canvas2D	2D spatial: objects, transforms, z-order, spatial queries
05	Timeline	Temporal: tracks, clips, keyframes, interpolation, overlap
06	Layers	Hierarchy: parent-child, visibility, locked, reparenting
07	NodeGraph	Graph: nodes, ports, edges, type matching, topo sort, Canvas2D composition
08	Viewport3D	3D spatial: Euler angles, parent-child, spatial queries
09	Table	Tabular: rows, columns, cells, merged cells, ordering
10	TextEditor	Text: Unicode positions, ranges, search/replace, line/column

Domain Foundation — Systems¶

#	Guide	Topic
11	Relations	Definitions, evaluation, propagation, batch, value source/sink
12	Utilities	Filtering, querying, tagging, sorting, grouping, validation, batch

Domain Foundation — Integration¶

#	Guide	Topic
13	Domain Engine Integration	How DomainEngine composes all environments + App Engine
14	App Engine Integration	Command handlers, EngineRef, history, events, signals
15	Operations & Undo	Operation pattern, outcomes, undo/redo, transactions, compound ops
16	Serialization	serde feature, round-trip, known limitations

Domain Foundation — Reference¶

#	Guide	Topic
17	Testing	Model, operation, integration, composition, acceptance, concurrency, proptest, stress
18	Public API Reference	Complete type/trait listing
19	Error Reference	All error types and variants
20	Quick Start	5-minute getting started with Domain Foundation

_{Built with ❤️ in Rust. Zero dependencies. No compromise.}
